Identification data

Country of origin:

D Germany

Make:

BMW

Model:

6-Series E24

1976-1989

Type:

6 E24/1 (series 2)

1982-1987

Optional equipment:

EEC segmentation:

S (sport cars)

Class:

grand tourer

Body style:

notchback coupe

Doors:

2

Traction:

RWD (rear-wheel drive)

Basic dimensions

Length:

4755 mm / 187.2 in

Width:

1725 mm / 67.9 in

Height:

1365 mm / 53.7 in

Wheelbase:

2625 mm / 103.3 in

Fuel capacity:

70 liter / 18.5 U.S. gal / 15.4 imp. gal

Drag coefficient (Cw-Wert):

Cd claimed:

0.41

Cd estimated by a-c:

Weights

Curb weight (without a driver):

1430 kg / 3153 lbs

Dry weight:

Shipping weight:

Curb weight estimated:

Gross weight GVWR:

1850 kg / 4078 lbs

Payload:

420 kg / 926 lbs

Payload estimated:

Sales markets

Powertrain

Engine manufacturer:

BMW M30 B32

Engine type:

spark-ignition 4-stroke

Fuel type:

petrol (gasoline)

Fuel system:

indirect injection

Charge system:

naturally aspirated

Valves per cylinder:

2

Valves timing:

Additional features:

Bosch Motronic

Emission control:

Emission standard:

Cylinders alignment:

Line 6

Displacement:

3210 cm3 / 195.7 cui

Power net:

145 kW / 197 PS / 194 hp (DIN)

/ 5500

Torque:

285 Nm / 210 ft-lb

/ 4300

Power gross:

Torque gross:

Drivetrain

Gearbox:

Getrag 265

Transmission type:

manual

Number of gears:

5

Standard tires:

205/70 VR 14
